EYEPIECE(S)
Pair of WF10x/20 mm eyepieces supplied with eyecups

HEAD
Binocular or trinocular 45° inclined tubes. Diopter adjustment on both eyepieces, except the models. SB.1302-P/ 1402-P and SB.1302 /1402, which have diopter. Adjustment on one side. Interpupillary distance adjustable between 55 mm and 75 mm. All optics are anti-fungus treated and anti-reflection coated for maximum light throughput

DUAL MAGNIFICATION OBJECTIVES
Nosepiece with dual 1x/3x or 2x/4x revolving objectives • Magnifications 10x/30x or 20x/40x. Field of view 20 mm/6.6 mm or 10 mm/5.0 mm. Working distance 100 mm

ZOOM OBJECTIVE
Zoom Stereo 0.7x to 4.5x parafocal objective Magnification from 7x to 45x. Field of view 28.5 mm to 4.4 mm. Working distance 100 mm

MAGNIFICATIONS
Working distance and field of view specifications

STANDS
The rack & pinion and pillar stands of the StereoBlue are equipped with ergonomically designed flat bases, complete with 2 object clamps and Ø 60 mm transparent and black/ white stage plate. The coarse adjustment is equipped with tension control

The ergonomically designed universal single arm stand is ideal for looking at large samples or working under the microscope. Standard supplied without illumination. Suitable for e.g. ring illuminators LE.1972 and LE.1973. The stands are alloy metal casted with hardened off-white coating

ILLUMINATION
With 3 W transmitted and incident LED illuminators which can be used simultaneously or adjusted seperately. SB.3903 and SB.3903-P models come with a built-in 30 LED ring light for reflexed illuminator and 3 W transmitted illuminator

PACKAGING
Supplied with power cord, dust cover, a spare fuse, Ø 60 mm transparent and black/ white stage plates and user manual. All packed in a polystyrene box
